60W Triac Dimmable Driver AC 120V To DC 12V Conversion Class 2 Safety Triac Dimmer Driver

Shenzhen Keysun Technology Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

60W Triac Dimmable Driver AC 120V To DC 12V Conversion Class 2 Safety Triac Dimmer Driver

Brand Name : KSPOWER

Model Number : KS-60AW-12P

Certification : UL FCC CE ROHS SAA CLASS P etc.

Place of Origin : Guangdong, China

MOQ : 50 pieces

Price : $19.86-21.98/pieces

Payment Terms : T/T,Western Union

Supply Ability : 300000pcs/month

Delivery Time : 15-25 days

Packaging Details : Inner box and outter box

Warranty(Year) : 5-Year

Lighting solutions service : Lighting and circuitry design

Output Power : 60W

Output Type : PWM

Input Voltage : 100-277V

Output Frequency : 50/60Hz

Product Name : 12V 60W LED Driver

Application : LED Strip Light,Pendants, Linears,Cove Lights

Material : Aluminum Case

Warranty : 5 years

Protection : OCP, OVP, SCP, OTP

IP Rate : IP65

Efficiency : ≥90%

Power : 60W

Output : 12V

Contact Now

60W Triac Dimmable Driver AC 120V To DC 12V Conversion Class 2 Safety Triac Dimmer Driver
The KS-80W is a versatile 40W 5-in-1 universal dimming driver that accepts 100-277VAC input voltage and provides 12V/24V/36V/48V constant voltage output. This flicker-free dimming solution works with all dimming systems including Triac, 0-10V, 1-10V, PWM, Resistance, MLV, ELV and Incandescent.
Key Features:
  • Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
  • Single Channel & Constant Voltage mode
  • Output Voltage: 24Volt
  • Driver Type: Class 2 Class P
  • Dimming: PWM, TRIAC, 0/1-10V or MLV/ELV Resistance Dimmable Available
  • Environmental: Dry and Damp locations
  • Wiring Compartments with Knock-Outs for Clean and Easy Installation
  • Current Limiting Overload Protection
  • Flicker-Free, Smooth Ripple Free Output Voltage
  • IP65 Rated Enclosure for Indoor and Outdoor Use
  • 5-Years Warranty
  • UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL
Packaging Information
1. Samples are available.
2. Shipping methods available: express DHL/UPS/FedEx/TNT, Land, Ocean and others.
3. For 60W power adapter: each one in small inner brown box, 50 pcs per standard carton.
Package Piece/Carton (pcs) Piece Weight (KG)
OEM package 50 0.26
Dimension/Brown Box (mm) Dimension/Carton (mm) Gross Weight/Carton (KG)
155*85*35 455*370*175 14

60W Triac Dimmable Driver AC 120V To DC 12V Conversion Class 2 Safety Triac Dimmer Driver

Dimming Type Series Power Model
(xx=output voltage)
Output voltage&
Output current
Input voltage Size
12V 24V 36V 48V
Triac/Phase-cut HTJ 40W KS-40AW-xxT 3.3A 1.67A 1.11A 0.83A 100~277V
50/60Hz
297*58*36mm
60W KS-60AW-xxT 5A 2.5A 1.67A 1.25A
80W KS-80AW-xxT 6.67A 3.33A 2.22A 1.67A
96W KS-96AW-24T / 4A / / 322*58*36mm
100W KS-100AW-xxT 8.33A 4.16A 2.78A 2.08A
120W KS-120AW-xxT 10A 5A 3.33A 2.5A
150W KS-150AW-xxT 12.5A 6.25A 4.16A 3.13A
180W KS-180AW-12T 15A / / / 343*68*41mm
200W KS-200AW-xxT 16.66A 8.33A 5.55A 4.16A
240W KS-240AW-xxT 20A 10A 6.66A 5A 367*68*41mm
300W KS-300AW-24T / 12.5A / /
320W KS-320AW-xxT / 13.33A 8.88A 6.66A


60W Triac Dimmable Driver AC 120V To DC 12V Conversion Class 2 Safety Triac Dimmer Driver
